Application Features
The TT Series Transformers are offered for use in coupling to telephone lines. The broad-band frequency response of 200-100 Khz accommodates voice or high speed data transmission. This series is for circuits with no D.C.
Like other pot cores, the “EP” is self-shielding to the extent it minimizes coupling to other components. To minimize interference from external magnetic fields, contact MCE Engineering Department for a novel solution.
Packaging Considerations
The EP core and bobbin designs provide for all the pins to be within the outline of the core, therefore minimizing board mounting area when compared to traditional pot cores.
The maximum height has been reduced to .51 inches to fit critical board spacing requirements.
Contact MCE for questions concerning packaging or modified standard parts including surface mount.
Spec Sheet List:
To view a spec sheet, click on the appropriate link below. A page will open in a new window and where you can zoom, print or save the document. After you are finished using the file, simply close the newly opened tab/window.
 | OE13TT rev-D Spec-Sheet | 34.5 KB |
| O-1408T1A rev-B Spec-Sheet | 69.6 KB |
| O-1880T1 rev-E Spec-Sheet | 95.0 KB |
